These three techniques form a powerful combination for managing fiber cabling networks or utilizing the fiber for Distributed Fiber Optic Sensing.Īlthough originally intended for long haul fiber optic applications, newer generation high resolution OTDR tools can also be used to diagnose much shorter cables, such as internal aircraft and enterprise facility cabling such as structured cabling.
#AUTO CONNECTOR TESTING PORTABLE#
The OTDR is also the only fiber testing tool capable of troubleshooting fiber optic cable failures by locating the distance to the fault and identifying the type and cause of the fault, including breaks, bends, bad connectors, and any excessive insertion loss “events”. To do this an OTDR uses the effects of Rayleigh scattering and Fresnel reflection to measure the condition of a fiber link, and while single-ended (uni-directional) tests can be performed, dual-ended bidirectional OTDR testing improves measurement accuracy event detection and is required in order to comply with the IEC and ITU-T testing standards.Īn OTDR instrument can be portable for transport from site to site or rack-mounted for permanent placement and monitoring of a network with alarms triggered automatically if the fiber is compromised.Īlong with the Rayleigh scattering method used to characterize fiber links, OTDR can also use Raman and Brillouin scattering effects to predict breaks, monitor fiber health, and prevent service outages through temperature and strain measurements. Troubleshoot Fiber Optic Cable Failures with OTDRs
#AUTO CONNECTOR TESTING PC#
Core Tuner tuning right at the same time can also detect naked insert Core concentricity, as well as the single Core insert Core, connectors, face detection.ĬORE TUNER not can ditect PC connectors,but also can detect APC connectors with out replacing fixture.Once this information has been captured, analyzed, and stored, it can be recalled as needed to evaluate the same cable over time.
#AUTO CONNECTOR TESTING SOFTWARE#
Here are 10 PCS tested pieces of charts and data, using 100000 times fixture repeat test after aging 20 times of the test data.Ĭore Tuner S at 2.5 mm / 1.25 mm Ferrule measurement mode, the single test task is completed, the hardware automatic adjust the Angle of Bearing to the required range, at the same time the software Interface indicates KEY position, convenient for the subsequent assembly work.Ĭore Tuner not only can measure the optical fiber connector after assembly concentricity, can also test of optical fiber connector assembly concentricity, and adjust the fiber Core of deviation Angle, labeled assembly position, so as to reduce the wastage of the optical fiber connector, the connector of the overall quality improved greatly. The mismatch between two fiber cores will cause large insert loss. The systems are automatic, intelligent, easy to use with strong vibration resistance and durability.įiber connector has loss in data-link due to many causes, such as horizontal mismatch, vertical mismatch and axial mismatch.The main cause of insert loss is horizontal mismatch. Superior image processing capabilities gives Core Tuner excellent performance-high numerical accuracy, repeatability. The instruments define new standards of concentricity machines.
Core Tuner is fiber optic connector concentricity testing and adjusting equipment developed by Dimension Technology based on many years of experience in instrument development.We developed two types of equipment- Core Tuner S (automatic) and Core Tuner (manual) to meet different requirements from customers.
